OVERCENTER

NOT BALANCED

Technical Specifications

TECHNICAL SPECIFICATIONS
Materials: body is steel made. Internal parts are in hardened steel. External surface: zinc plated.
Rated flow: up to 90 l/min
Max. setting: 350 bar
Adjustement means: leakproof screw adjustement
Adjustable pressure range: see page 02
Cavità: 33141

Download

CAVITY DIMENSIONS
